EAP600X
AX3000 Ceiling Access Point
WIFI 6 AX3000, Simultaneous dual band, POE, WDT & UL/DL MIMO, OFDMA, 1024QAM support
Main wireless characteristics:
●Simultaneous dual band, 802.11ax (2.4GHz and 5GHz)
●WIFI 6 AX3000 technology, transmission data rate is up to 2976Mbps.
●WAP 3 protocol and IPv6 standards.
●WIFI 5 and former standards also compatible.
EAP600X is dual band with up to 576Mbps in 2.4GHz band and up to 2402Mbps in 5GHz band, simultaneously
can achieve up to 2976Mbps WIFI speed.
It has 2 spatial streams and 2 antennas in MU-MIMO 2T2R configuration, supports OFDMA technology, so can
use in high-density environments to connect more devices.
EAP600X access point uses ARM Quad-core CPU, plus 1024QAM technology, that’s incredibly decreased packet
loss and network latency when more devices connect at the same time.
This access point supports WDT, watch-dog timer, and meets latest WAP3 protocol, EAP600X protects users'
wireless connects strictly.
Hardware
Wireless Standards | Wi-Fi 6: 5.8 GHzIEEE 802.11ax/ac/n/a 2.4 GHz IEEE 802.11ax/n/b/g | |||
Signal Rate | AX3000: 5 GHz: 2402 Mbps (802.11ax, HE160) 2.4 GHz: 574 Mbps (802.11ax) | |||
Antenna Type | 5GHz 6 dBi, Omni 2.4GHz 6 dBi, Omni | |||
Max EIRP | 5 GHz 33dBm 2.4 GHz 33 dBm * EIRP may be limited by country regulations | |||
SOC | 1.0 GHz Quad-Core CPU | |||
RAM | 4Gb | |||
FLASH | 1Gb NAND FLASH | |||
Interface | 1xGigabit Port | |||
LEDs | 3LEDs | |||
Dimensions (D x H) | 112*72mm | |||
Environment | Operating Temperature:-20℃ ~ 45℃ Storage Temperature:-40℃ ~ 75℃ Operating Humidity:10% ~ 90%RH non-condensing Storage Humidity:5% ~ 90%RH non-condensing | |||
Protection Grade | 15KV ESD Protection | |||
Power Consumption | ≤18W | |||
Power Supply | 48V 500mA 802.at POE | |||
Button | Reset | |||
Package Contents | 1 EAP600X 1 User Guide 1 Warranty Card 1 CAT 5E |
Software
Operating Mode | Access Point DHCP Router | |||
Number of Access User Device | 128(526) | |||
Networking Mode | WiFi Hotspot DHCP Router | |||
Centralized Management | WEB Management WAG Wireless Controller E Cloud-Based Controller | |||
Wireless Security | WPA、WPA2、WPA3 Encryption | |||
System Upgrade | WEB Local Upgrade, Centralized Online Upgrade |
